TIDE 36
Built by MFH (Ger)
• Designed by Marc-Oliver v. Ahlen
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
GRP
First Built:
2022
Dimensions
Length Overall (LOA):
10.70 m
Length Waterline (LWL):
9.68 m
Beam:
3.02 m
Draft (Max):
1.90 m
Max Height:
14.20 m
Weight & Ballast
Displacement:
3,800 kg
Ballast:
1,200 kg
Sail Plan
Sail Area (reported):
61.00 m²
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
19 HP
Fuel Capacity:
90 L
Water Capacity:
140 L
Performance Ratios
Hull Speed:
7.55 knots
SA/Displacement (Reported):
25.55
Ballast/Disp Ratio:
31.58%
Displacement/Length:
116.74
Comfort Ratio:
18.62
Capsize Screening:
1.95
Notes
Shallow keel option: draft - 1.65 m / 5.4 ft
