TICON 30
Built by Ticon Yachts Ltd. (CAN)
• Designed by Halsey Herreshoff
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1981
Last Built:
1986
Number Built:
35
Dimensions
Length Overall (LOA):
9.12 m
Length Waterline (LWL):
7.92 m
Beam:
3.35 m
Draft (Max):
1.50 m
Headroom:
1.91 m
Weight & Ballast
Displacement:
4,354 kg
Ballast:
1,928 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
19.60 m²
Mainsail Area:
20.74 m²
Total Sail Area (calculated):
40.34 m²
Sail Area (reported):
40.32 m²
I (Fore Triangle Height):
11.43 m
J (Fore Triangle Base):
3.43 m
P (Mainsail Hoist):
11.58 m
E (Boom Length):
3.58 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Model:
5411
Engine Power:
11 HP
Fuel Capacity:
76 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.83 knots
SA/Displacement (Calculated):
15.13
SA/Displacement (Reported):
15.42
Ballast/Disp Ratio:
44.27%
Displacement/Length:
243.84
Comfort Ratio:
22.39
Capsize Screening:
2.07
S-Number:
2.08
Notes
Shoal Keel vers.: draft 3.92'; displacement 9,900 lbs; ballast 4.550 lbs
