THOMAS 35
Built by Thomas Marine Inc./Tartan Marine (USA)
• Designed by Graham & Schlageter
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1988
Dimensions
Length Overall (LOA):
10.80 m
Length Waterline (LWL):
9.30 m
Beam:
3.51 m
Draft (Max):
2.08 m
Weight & Ballast
Displacement:
4,445 kg
Ballast:
2,018 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
31.77 m²
Mainsail Area:
33.45 m²
Total Sail Area (calculated):
65.22 m²
Sail Area (reported):
65.22 m²
I (Fore Triangle Height):
14.63 m
J (Fore Triangle Base):
4.34 m
P (Mainsail Hoist):
14.63 m
E (Boom Length):
4.57 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM
Engine Power:
27 HP
Fuel Capacity:
76 L
Water Capacity:
132 L
Performance Ratios
Hull Speed:
7.40 knots
SA/Displacement (Calculated):
24.12
SA/Displacement (Reported):
24.61
Ballast/Disp Ratio:
45.41%
Displacement/Length:
154.20
Comfort Ratio:
18.31
Capsize Screening:
2.15
S-Number:
4.28
Notes
Also promoted as T-35.
