TAYANA 64
Built by Ta Yang Yacht Building Co. (TAIWAN)
• Designed by Robert Ladd
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
Construction:
FG Vinylester/PVC hull/Balsa deck
First Built:
2003
Dimensions
Length Overall (LOA):
19.43 m
Length Waterline (LWL):
17.02 m
Beam:
5.50 m
Draft (Max):
2.44 m
Weight & Ballast
Displacement:
27,714 kg
Ballast:
9,550 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
192.77 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4LHA-HTP
Engine Power:
160 HP
Fuel Capacity:
2,048 L
Water Capacity:
1,158 L
Performance Ratios
Hull Speed:
10.01 knots
SA/Displacement (Reported):
21.50
Ballast/Disp Ratio:
34.46%
Displacement/Length:
156.57
Comfort Ratio:
34.43
Capsize Screening:
1.84
Notes
Shoal draft vers. 6.83'/2.08m
