TAYANA 48
Built by Ta Yang Yacht Building Co. (TAIWAN)
• Designed by Robert Perry
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Cutter
Construction:
FRP w/PVC foam core
First Built:
1992
Dimensions
Length Overall (LOA):
14.63 m
Length Waterline (LWL):
12.27 m
Beam:
4.42 m
Draft (Max):
1.83 m
Weight & Ballast
Displacement:
15,876 kg
Ballast:
5,296 kg
Ballast Type:
Cast iron
Sail Plan
Sail Area (reported):
122.26 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
4JH3-TE
Engine Power:
75 HP
Fuel Capacity:
454 L
Water Capacity:
833 L
Performance Ratios
Hull Speed:
8.50 knots
SA/Displacement (Reported):
19.76
Ballast/Disp Ratio:
33.36%
Displacement/Length:
239.62
Comfort Ratio:
36.09
Capsize Screening:
1.78
Notes
Shoal draft: 5.25ft / 1.6m
