TAYANA 37
Built by Ta Yang Yacht Building Co. (TAIWAN)
• Designed by Robert Perry
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1976
Number Built:
588
Dimensions
Length Overall (LOA):
11.18 m
Length Waterline (LWL):
9.45 m
Beam:
3.51 m
Draft (Max):
1.73 m
Weight & Ballast
Displacement:
10,206 kg
Ballast:
3,629 kg
Sail Plan
Foresail Area:
46.01 m²
Mainsail Area:
32.62 m²
Total Sail Area (calculated):
78.63 m²
Sail Area (reported):
79.99 m²
I (Fore Triangle Height):
15.48 m
J (Fore Triangle Base):
5.94 m
P (Mainsail Hoist):
13.81 m
E (Boom Length):
4.72 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
341 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.46 knots
SA/Displacement (Calculated):
16.71
SA/Displacement (Reported):
17.35
Ballast/Disp Ratio:
35.56%
Displacement/Length:
337.17
Comfort Ratio:
41.11
Capsize Screening:
1.63
S-Number:
1.49
Notes
The design was commissioned by Will Eckert, a partner in Flying Dutchman Yachts, along with C.T. Chen of the Ta Yang Yacht Building. First called TA CHIAO 37. 40 were built as the TA YANG 37.
