TARTAN 41
Built by Tartan Marine (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1972
Last Built:
1976
Number Built:
80
Dimensions
Length Overall (LOA):
12.38 m
Length Waterline (LWL):
9.96 m
Beam:
3.73 m
Draft (Max):
2.07 m
Weight & Ballast
Displacement:
8,097 kg
Ballast:
4,173 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
41.32 m²
Mainsail Area:
26.00 m²
Total Sail Area (calculated):
67.32 m²
Sail Area (reported):
67.35 m²
I (Fore Triangle Height):
15.54 m
J (Fore Triangle Base):
5.32 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
3.79 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Model:
Pilot 20
Engine Power:
20 HP
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.66 knots
SA/Displacement (Calculated):
16.70
SA/Displacement (Reported):
17.05
Ballast/Disp Ratio:
51.54%
Displacement/Length:
228.53
Comfort Ratio:
27.97
Capsize Screening:
1.88
S-Number:
2.39
Notes
S&S design #2095.
