TARTAN 40
Built by Tartan Marine (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Last Built:
1989
Number Built:
72
Dimensions
Length Overall (LOA):
12.27 m
Length Waterline (LWL):
9.63 m
Beam:
3.87 m
Draft (Max):
2.29 m
Weight & Ballast
Displacement:
7,824 kg
Ballast:
3,447 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
37.90 m²
Mainsail Area:
29.54 m²
Total Sail Area (calculated):
67.44 m²
Sail Area (reported):
67.54 m²
I (Fore Triangle Height):
15.54 m
J (Fore Triangle Base):
4.88 m
P (Mainsail Hoist):
13.84 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
178 L
Water Capacity:
511 L
Performance Ratios
Hull Speed:
7.53 knots
SA/Displacement (Calculated):
17.11
SA/Displacement (Reported):
17.49
Ballast/Disp Ratio:
44.06%
Displacement/Length:
244.51
Comfort Ratio:
26.43
Capsize Screening:
1.97
S-Number:
2.27
Notes
S&S design #2481. Available in a number of different keel and rig configurations.
