TARTAN 37 (S&S)
Built by Tartan Marine (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Keel/CB w/rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG w/balsa cored hull & deck
First Built:
1976
Last Built:
1989
Number Built:
486
Dimensions
Length Overall (LOA):
11.37 m
Length Waterline (LWL):
9.78 m
Beam:
3.58 m
Draft (Max):
2.36 m
Draft (Min):
1.27 m
Max Height:
15.70 m
Weight & Ballast
Displacement:
8,074 kg
Ballast:
3,402 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
34.93 m²
Mainsail Area:
23.13 m²
Total Sail Area (calculated):
58.06 m²
Sail Area (reported):
58.06 m²
I (Fore Triangle Height):
14.33 m
J (Fore Triangle Base):
4.88 m
P (Mainsail Hoist):
12.65 m
E (Boom Length):
3.66 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Model:
4-107
Engine Power:
40 HP
Fuel Capacity:
189 L
Water Capacity:
341 L
Performance Ratios
Hull Speed:
7.59 knots
SA/Displacement (Calculated):
14.43
SA/Displacement (Reported):
14.72
Ballast/Disp Ratio:
42.13%
Displacement/Length:
240.70
Comfort Ratio:
30.72
Capsize Screening:
1.80
S-Number:
2.03
Notes
(S&S design #2253) Sometimes referred to as TARTAN 37C.
