TARTAN 365
Built by Tartan Marine
• Designed by Tim Jackett
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Solent
Construction:
FG
First Built:
2020
Dimensions
Length Overall (LOA):
11.13 m
Length Waterline (LWL):
9.47 m
Beam:
3.66 m
Draft (Max):
1.98 m
Max Height:
17.68 m
Weight & Ballast
Displacement:
5,840 kg
Ballast:
1,928 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
30.71 m²
Mainsail Area:
34.63 m²
Total Sail Area (calculated):
65.34 m²
Sail Area (reported):
65.34 m²
I (Fore Triangle Height):
14.65 m
J (Fore Triangle Base):
4.19 m
P (Mainsail Hoist):
14.43 m
E (Boom Length):
4.80 m
Engine & Systems
Engine Type:
Diesel; Saildrive
Engine Power:
30 HP
Fuel Capacity:
132 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.47 knots
SA/Displacement (Calculated):
20.15
SA/Displacement (Reported):
20.56
Ballast/Disp Ratio:
33.01%
Displacement/Length:
191.45
Comfort Ratio:
22.23
Capsize Screening:
2.05
S-Number:
3.22
Notes
Beavertail keel: draft - 4.92ft; Displacement - 13,375 lbs; Ballast - 4,750 lbs.
