TARTAN 3400/345
Built by Tartan Marine
• Designed by Tim Jackett
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
2002
Dimensions
Length Overall (LOA):
10.49 m
Length Waterline (LWL):
9.27 m
Beam:
3.63 m
Draft (Max):
1.98 m
Max Height:
16.76 m
Weight & Ballast
Displacement:
4,899 kg
Ballast:
1,588 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
27.24 m²
Mainsail Area:
30.37 m²
Total Sail Area (calculated):
57.61 m²
Sail Area (reported):
57.60 m²
I (Fore Triangle Height):
14.02 m
J (Fore Triangle Base):
3.89 m
P (Mainsail Hoist):
13.51 m
E (Boom Length):
4.50 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
30 HP
Fuel Capacity:
95 L
Water Capacity:
227 L
Performance Ratios
Hull Speed:
7.39 knots
SA/Displacement (Calculated):
19.98
SA/Displacement (Reported):
20.37
Ballast/Disp Ratio:
32.41%
Displacement/Length:
171.28
Comfort Ratio:
19.46
Capsize Screening:
2.16
S-Number:
3.50
Notes
Alternate keels:
