TARTAN 34-2
Built by Tartan Marine (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Last Built:
1989
Number Built:
110
Dimensions
Length Overall (LOA):
10.49 m
Length Waterline (LWL):
8.79 m
Beam:
3.34 m
Draft (Max):
1.91 m
Weight & Ballast
Displacement:
4,990 kg
Ballast:
1,996 kg
Sail Plan
Foresail Area:
28.30 m²
Mainsail Area:
21.67 m²
Total Sail Area (calculated):
49.97 m²
Sail Area (reported):
49.98 m²
I (Fore Triangle Height):
13.66 m
J (Fore Triangle Base):
4.15 m
P (Mainsail Hoist):
11.95 m
E (Boom Length):
3.63 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM
Engine Power:
27 HP
Fuel Capacity:
87 L
Water Capacity:
216 L
Performance Ratios
Hull Speed:
7.19 knots
SA/Displacement (Calculated):
17.11
SA/Displacement (Reported):
17.46
Ballast/Disp Ratio:
40.00%
Displacement/Length:
204.93
Comfort Ratio:
22.97
Capsize Screening:
1.97
S-Number:
2.70
Notes
The TARTAN 34-2 is updated version of the earlier S&S designed TARTAN 33R with a extended stern and modified interior.
