TANZER 22
Built by Tanzer Industries Ltd. (CAN)
• Designed by Johann Tanzer
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Last Built:
1986
Number Built:
2271
Dimensions
Length Overall (LOA):
6.86 m
Length Waterline (LWL):
6.02 m
Beam:
2.39 m
Draft (Max):
1.04 m
Max Height:
9.45 m
Weight & Ballast
Displacement:
1,315 kg
Ballast:
567 kg
Sail Plan
Foresail Area:
11.30 m²
Mainsail Area:
9.62 m²
Total Sail Area (calculated):
20.92 m²
Sail Area (reported):
20.90 m²
I (Fore Triangle Height):
8.67 m
J (Fore Triangle Base):
2.61 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
5.96 knots
SA/Displacement (Calculated):
17.43
SA/Displacement (Reported):
17.75
Ballast/Disp Ratio:
43.10%
Displacement/Length:
168.05
Comfort Ratio:
14.04
Capsize Screening:
2.20
S-Number:
3.21
Notes
The TANZER 22 was the most popular of all the Tanzer models. Most were constructed in Dorion, Que.(CAN). But some were produced in Edenton., N.C. (USA), (270 boats) and in Arlington, WA (USA). (167 boats).
