TANZER 10.5
Built by Tanzer Industries Ltd. (CAN)
• Designed by Dick Carter/Johann Tanzer
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1983
Dimensions
Length Overall (LOA):
10.49 m
Length Waterline (LWL):
8.38 m
Beam:
3.51 m
Draft (Max):
1.98 m
Draft (Min):
0.63 m
Weight & Ballast
Displacement:
5,897 kg
Ballast:
2,585 kg
Sail Plan
Foresail Area:
28.36 m²
Mainsail Area:
22.83 m²
Total Sail Area (calculated):
51.19 m²
Sail Area (reported):
51.19 m²
I (Fore Triangle Height):
13.11 m
J (Fore Triangle Base):
4.33 m
P (Mainsail Hoist):
11.52 m
E (Boom Length):
3.96 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
30 HP
Performance Ratios
Hull Speed:
7.03 knots
SA/Displacement (Calculated):
15.68
SA/Displacement (Reported):
16.00
Ballast/Disp Ratio:
43.85%
Displacement/Length:
279.06
Comfort Ratio:
26.26
Capsize Screening:
1.96
S-Number:
1.83
Notes
The TANZER 10.5 featured a pilothouse with inside steering and was offered in fixed, and lifting keel versions.
