SWEDEN YACHTS 36
Built by Sweden Yachts
• Designed by Peter Norlin
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Last Built:
1992
Number Built:
74
Dimensions
Length Overall (LOA):
11.00 m
Length Waterline (LWL):
8.99 m
Beam:
3.66 m
Draft (Max):
2.04 m
Weight & Ballast
Displacement:
6,486 kg
Ballast:
2,699 kg
Sail Plan
Foresail Area:
34.01 m²
Mainsail Area:
26.35 m²
Total Sail Area (calculated):
60.36 m²
Sail Area (reported):
60.39 m²
I (Fore Triangle Height):
15.18 m
J (Fore Triangle Base):
4.48 m
P (Mainsail Hoist):
13.20 m
E (Boom Length):
3.99 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
2003
Engine Power:
28 HP
Performance Ratios
Hull Speed:
7.28 knots
SA/Displacement (Calculated):
17.35
SA/Displacement (Reported):
17.72
Ballast/Disp Ratio:
41.61%
Displacement/Length:
248.67
Comfort Ratio:
25.65
Capsize Screening:
1.98
S-Number:
2.25
Notes
Also available with a shallow draft wing keel.
