SWAN 57 RS
Built by Nautor
• Designed by German Frers
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1996
Last Built:
2001
Number Built:
10
Dimensions
Length Overall (LOA):
17.49 m
Length Waterline (LWL):
13.57 m
Beam:
4.85 m
Draft (Max):
2.30 m
Weight & Ballast
Displacement:
24,500 kg
Ballast:
9,230 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
66.63 m²
Mainsail Area:
58.78 m²
Total Sail Area (calculated):
125.41 m²
Sail Area (reported):
125.42 m²
I (Fore Triangle Height):
21.15 m
J (Fore Triangle Base):
6.30 m
P (Mainsail Hoist):
18.66 m
E (Boom Length):
6.30 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Power:
125 HP
Fuel Capacity:
1,049 L
Water Capacity:
1,030 L
Performance Ratios
Hull Speed:
8.94 knots
SA/Displacement (Calculated):
14.87
SA/Displacement (Reported):
15.18
Ballast/Disp Ratio:
37.67%
Displacement/Length:
273.27
Comfort Ratio:
43.32
Capsize Screening:
1.69
S-Number:
1.80
Notes
RS=raised salon.
