SWAN 54
Built by Nautor Swan (FIN)
• Designed by German Frers
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
GRP
First Built:
2016
Dimensions
Length Overall (LOA):
16.48 m
Length Waterline (LWL):
14.40 m
Beam:
4.75 m
Draft (Max):
2.44 m
Weight & Ballast
Displacement:
21,999 kg
Ballast:
8,210 kg
Sail Plan
Foresail Area:
62.08 m²
Mainsail Area:
67.26 m²
Total Sail Area (calculated):
129.34 m²
Sail Area (reported):
142.88 m²
I (Fore Triangle Height):
20.87 m
J (Fore Triangle Base):
5.95 m
P (Mainsail Hoist):
20.08 m
E (Boom Length):
6.70 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
110 HP
Fuel Capacity:
600 L
Water Capacity:
730 L
Performance Ratios
Hull Speed:
9.21 knots
SA/Displacement (Calculated):
16.48
SA/Displacement (Reported):
18.59
Ballast/Disp Ratio:
37.32%
Displacement/Length:
205.38
Comfort Ratio:
39.26
Capsize Screening:
1.71
S-Number:
2.62
Notes
Interior design: Heini Gustafsson
