SWAN 48-3 (FRERS)
Built by Nautor (FIN)
• Designed by Germán Frers
General Information
Hull Type:
Fin w/bulb & dual rudders
Rigging Type:
Fractional Sloop
Construction:
GRP
First Built:
2019
Dimensions
Length Overall (LOA):
15.78 m
Length Waterline (LWL):
13.88 m
Beam:
4.59 m
Draft (Max):
2.40 m
Weight & Ballast
Displacement:
15,000 kg
Ballast:
5,200 kg
Sail Plan
Foresail Area:
58.86 m²
Mainsail Area:
65.66 m²
Total Sail Area (calculated):
124.52 m²
Sail Area (reported):
139.60 m²
I (Fore Triangle Height):
20.80 m
J (Fore Triangle Base):
5.66 m
P (Mainsail Hoist):
19.90 m
E (Boom Length):
6.60 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel; Saildrive
Engine Model:
D2-75
Engine Power:
75 HP
Fuel Capacity:
360 L
Water Capacity:
500 L
Performance Ratios
Hull Speed:
9.04 knots
SA/Displacement (Calculated):
20.47
SA/Displacement (Reported):
23.43
Ballast/Disp Ratio:
34.67%
Displacement/Length:
156.31
Comfort Ratio:
29.12
Capsize Screening:
1.88
S-Number:
3.80
Notes
Length of hull: 14.78 m / 48.49 ft.
