SWAN 391
Built by Nautor
• Designed by Ron Holland
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1981
Last Built:
1987
Number Built:
52
Dimensions
Length Overall (LOA):
12.17 m
Length Waterline (LWL):
10.08 m
Beam:
3.79 m
Draft (Max):
2.19 m
Weight & Ballast
Displacement:
8,573 kg
Ballast:
3,084 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
40.51 m²
Mainsail Area:
30.76 m²
Total Sail Area (calculated):
71.27 m²
Sail Area (reported):
71.26 m²
I (Fore Triangle Height):
16.31 m
J (Fore Triangle Base):
4.97 m
P (Mainsail Hoist):
14.42 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Performance Ratios
Hull Speed:
7.71 knots
SA/Displacement (Calculated):
17.01
SA/Displacement (Reported):
17.36
Ballast/Disp Ratio:
35.98%
Displacement/Length:
233.09
Comfort Ratio:
29.02
Capsize Screening:
1.87
S-Number:
2.38
Notes
Shallow draft: 5.5'.
