SWAN 39
Built by Nautor
• Designed by Ron Holland
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1978
Last Built:
1980
Number Built:
33
Dimensions
Length Overall (LOA):
11.98 m
Length Waterline (LWL):
9.60 m
Beam:
3.81 m
Draft (Max):
2.19 m
Weight & Ballast
Displacement:
8,165 kg
Ballast:
3,583 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
41.39 m²
Mainsail Area:
29.35 m²
Total Sail Area (calculated):
70.74 m²
Sail Area (reported):
70.70 m²
I (Fore Triangle Height):
16.46 m
J (Fore Triangle Base):
5.03 m
P (Mainsail Hoist):
14.48 m
E (Boom Length):
4.05 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4-108
Fuel Capacity:
121 L
Water Capacity:
303 L
Performance Ratios
Hull Speed:
7.52 knots
SA/Displacement (Calculated):
17.44
SA/Displacement (Reported):
17.79
Ballast/Disp Ratio:
43.89%
Displacement/Length:
257.09
Comfort Ratio:
28.45
Capsize Screening:
1.91
S-Number:
2.18
Notes
Based on 'IMP'(1977), one of the most succesful IOR racers of its day.
