SWAN 36
Built by Nautor
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1967
Last Built:
1970
Number Built:
80
Dimensions
Length Overall (LOA):
10.89 m
Length Waterline (LWL):
7.90 m
Beam:
2.95 m
Draft (Max):
1.85 m
Weight & Ballast
Displacement:
6,486 kg
Ballast:
3,600 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
27.74 m²
Mainsail Area:
23.15 m²
Total Sail Area (calculated):
50.89 m²
Sail Area (reported):
50.73 m²
I (Fore Triangle Height):
13.00 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
10.85 m
E (Boom Length):
4.27 m
Engine & Systems
Performance Ratios
Hull Speed:
6.82 knots
SA/Displacement (Calculated):
14.63
SA/Displacement (Reported):
14.88
Ballast/Disp Ratio:
55.50%
Displacement/Length:
366.59
Comfort Ratio:
37.23
Capsize Screening:
1.60
S-Number:
1.18
Notes
S&S design #1710.31
