SUNRAY 21
Built by Cobramold Ltd./Sun Yachts Ltd. (UK)
• Designed by Arthur Howard
General Information
Hull Type:
Twin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Dimensions
Length Overall (LOA):
6.32 m
Length Waterline (LWL):
5.33 m
Beam:
2.44 m
Draft (Max):
0.76 m
Weight & Ballast
Displacement:
1,179 kg
Ballast:
526 kg
Sail Plan
Sail Area (reported):
19.05 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.61 knots
SA/Displacement (Reported):
17.39
Ballast/Disp Ratio:
44.62%
Displacement/Length:
216.58
Comfort Ratio:
13.63
Capsize Screening:
2.33
Notes
Single fin or twin keel versions were available.
