BLUEJACKET 23 MS
Built by Halman Manufacturing/Collingwood Yachts (CAN)
• Designed by William Garden
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Dimensions
Length Overall (LOA):
7.39 m
Length Waterline (LWL):
6.32 m
Beam:
3.05 m
Draft (Max):
0.69 m
Weight & Ballast
Displacement:
2,722 kg
Ballast:
318 kg
Sail Plan
Sail Area (reported):
19.97 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
1GM
Engine Power:
18 HP
Fuel Capacity:
91 L
Water Capacity:
57 L
Performance Ratios
Hull Speed:
6.10 knots
SA/Displacement (Reported):
10.45
Ballast/Disp Ratio:
11.67%
Displacement/Length:
299.81
Comfort Ratio:
19.81
Capsize Screening:
2.20
Notes
Motorsailer based on an earlier, Garden designed, catboat. ('Reddit' says this was the FAMILY CAT built by Halman.) Features twin station steering. It's thought that less than 10 were built.
