SUNBEAM ONE DESIGN
Built by Woodnutt & Co (UK)
• Designed by Alfred Westmacott
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
Construction:
Wood
First Built:
1922
Number Built:
44
Dimensions
Length Overall (LOA):
8.10 m
Length Waterline (LWL):
5.33 m
Beam:
1.83 m
Draft (Max):
1.14 m
Weight & Ballast
Displacement:
3,000 kg
Ballast:
864 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
27.87 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.61 knots
SA/Displacement (Reported):
13.66
Ballast/Disp Ratio:
28.79%
Displacement/Length:
550.94
Comfort Ratio:
46.42
Capsize Screening:
1.28
Notes
Since the orginal SUNBEAMS were built in the 1920's, the class has maintained racing fleets, almost continually, to this day.
