SUNBEAM 42.1
Built by Schöchl Yacthbau
• Designed by Georg Nissen/Schöchl
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
GRP using ISO/NPG resin
First Built:
2009
Last Built:
2021
Number Built:
29
Dimensions
Length Overall (LOA):
12.90 m
Length Waterline (LWL):
11.45 m
Beam:
3.98 m
Draft (Max):
2.10 m
Weight & Ballast
Displacement:
10,500 kg
Ballast:
3,800 kg
Ballast Type:
Cast iron
Sail Plan
Sail Area (reported):
91.00 m²
Engine & Systems
Engine Make:
Volvo-Penta
Engine Type:
Diesel, Shaft drive
Engine Model:
D2-55
Engine Power:
55 HP
Fuel Capacity:
415 L
Water Capacity:
466 L
Performance Ratios
Hull Speed:
8.21 knots
SA/Displacement (Reported):
19.37
Ballast/Disp Ratio:
36.19%
Displacement/Length:
194.88
Comfort Ratio:
29.95
Capsize Screening:
1.84
Notes
Shallow keel: draft - 1.75m / 5.75 ft
