SUNBEAM 36.1
Built by Sunbeam Yachts - Schöchl Yachtbau
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2012
Dimensions
Length Overall (LOA):
11.02 m
Length Waterline (LWL):
9.45 m
Beam:
3.42 m
Draft (Max):
1.94 m
Draft (Min):
1.52 m
Headroom:
1.95 m
Weight & Ballast
Displacement:
6,250 kg
Ballast:
2,050 kg
Sail Plan
Sail Area (reported):
59.92 m²
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Power:
28 HP
Fuel Capacity:
144 L
Water Capacity:
307 L
Performance Ratios
Hull Speed:
7.46 knots
SA/Displacement (Reported):
18.02
Ballast/Disp Ratio:
32.80%
Displacement/Length:
206.48
Comfort Ratio:
26.14
Capsize Screening:
1.88
Notes
Shallow draft: 1.52m
