SUNBEAM 28.1
Built by Sunbeam Yachts
• Designed by J&J Design
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
GRP
First Built:
2012
Last Built:
2021
Number Built:
92
Dimensions
Length Overall (LOA):
8.50 m
Length Waterline (LWL):
7.88 m
Beam:
2.49 m
Draft (Max):
1.65 m
Headroom:
1.65 m
Weight & Ballast
Displacement:
2,300 kg
Ballast:
750 kg
Sail Plan
Sail Area (reported):
38.00 m²
Engine & Systems
Engine Type:
Diesel
Engine Power:
13.4 HP
Fuel Capacity:
40 L
Water Capacity:
20 L
Performance Ratios
Hull Speed:
6.81 knots
SA/Displacement (Reported):
22.24
Ballast/Disp Ratio:
32.60%
Displacement/Length:
131.06
Comfort Ratio:
18.04
Capsize Screening:
1.90
Notes
Optional e-motor: 4.3 kW / 5.8 hp
