SUNBEAM 20
Built by Schöchl Yachtbau
• Designed by Georg Nissen
General Information
Hull Type:
Swing Keel
Rigging Type:
B&R
Construction:
FG
First Built:
2000
Dimensions
Length Overall (LOA):
6.44 m
Length Waterline (LWL):
5.80 m
Beam:
2.50 m
Draft (Max):
1.30 m
Draft (Min):
0.69 m
Weight & Ballast
Displacement:
980 kg
Ballast:
360 kg
Sail Plan
Sail Area (reported):
26.20 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.85 knots
SA/Displacement (Reported):
27.06
Ballast/Disp Ratio:
36.74%
Displacement/Length:
139.99
Comfort Ratio:
10.30
Capsize Screening:
2.54
Notes
Finn keel version: draft - 1,30 m/4.26'
