SUN RISE 34 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Jacques Fauroux
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Last Built:
1989
Number Built:
629
Dimensions
Length Overall (LOA):
10.54 m
Length Waterline (LWL):
8.99 m
Beam:
3.49 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
4,700 kg
Ballast:
1,569 kg
Sail Plan
Foresail Area:
27.56 m²
Mainsail Area:
20.35 m²
Total Sail Area (calculated):
47.91 m²
Sail Area (reported):
47.94 m²
I (Fore Triangle Height):
13.11 m
J (Fore Triangle Base):
4.21 m
P (Mainsail Hoist):
11.61 m
E (Boom Length):
3.51 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20F
Fuel Capacity:
68 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
7.28 knots
SA/Displacement (Calculated):
17.08
SA/Displacement (Reported):
17.43
Ballast/Disp Ratio:
33.39%
Displacement/Length:
180.17
Comfort Ratio:
20.07
Capsize Screening:
2.10
S-Number:
3.01
Notes
Available in 'Team' and 'Owners' versions.
