SUN ODYSSEY 42.2 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Guy Ribadeau Dumas
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1995
Last Built:
2000
Dimensions
Length Overall (LOA):
12.80 m
Length Waterline (LWL):
10.15 m
Beam:
4.10 m
Draft (Max):
2.00 m
Weight & Ballast
Displacement:
8,400 kg
Ballast:
2,610 kg
Sail Plan
Foresail Area:
32.55 m²
Mainsail Area:
32.66 m²
Total Sail Area (calculated):
65.21 m²
Sail Area (reported):
87.80 m²
I (Fore Triangle Height):
15.50 m
J (Fore Triangle Base):
4.20 m
P (Mainsail Hoist):
13.90 m
E (Boom Length):
4.70 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
50 HP
Fuel Capacity:
175 L
Water Capacity:
440 L
Performance Ratios
Hull Speed:
7.73 knots
SA/Displacement (Calculated):
15.78
SA/Displacement (Reported):
21.68
Ballast/Disp Ratio:
31.07%
Displacement/Length:
223.89
Comfort Ratio:
25.02
Capsize Screening:
2.04
S-Number:
2.34
Notes
Updated version of VOYAGE 12.50. This hull was used to build the SO 42 CC as well.
