SUN ODYSSEY 319 (JEANNEAU)
Built by Jeanneau
• Designed by Jeanneau Design
General Information
Hull Type:
Fin w/bulb & dual rudders
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2018
Dimensions
Length Overall (LOA):
9.99 m
Length Waterline (LWL):
9.09 m
Beam:
3.46 m
Draft (Max):
1.85 m
Max Height:
13.56 m
Weight & Ballast
Displacement:
5,100 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
20.17 m²
Mainsail Area:
20.48 m²
Total Sail Area (calculated):
40.65 m²
Sail Area (reported):
45.40 m²
I (Fore Triangle Height):
11.10 m
J (Fore Triangle Base):
3.63 m
P (Mainsail Hoist):
10.82 m
E (Boom Length):
3.79 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
21 HP
Fuel Capacity:
100 L
Water Capacity:
150 L
Performance Ratios
Hull Speed:
7.32 knots
SA/Displacement (Calculated):
13.72
SA/Displacement (Reported):
15.63
Displacement/Length:
189.30
Comfort Ratio:
22.27
Capsize Screening:
2.03
S-Number:
2.44
Notes
Available with swing keel. Draft: 2.42'-5.5' (0.75 - 1.70m). This version has the keel box under the saloon table.
