SUN LIGHT 30 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Daniel Andrieu
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1986
Dimensions
Length Overall (LOA):
9.15 m
Length Waterline (LWL):
7.70 m
Beam:
3.23 m
Draft (Max):
1.78 m
Weight & Ballast
Displacement:
3,100 kg
Ballast:
1,202 kg
Sail Plan
Foresail Area:
22.92 m²
Mainsail Area:
17.84 m²
Total Sail Area (calculated):
40.76 m²
Sail Area (reported):
40.78 m²
I (Fore Triangle Height):
12.55 m
J (Fore Triangle Base):
3.65 m
P (Mainsail Hoist):
11.15 m
E (Boom Length):
3.20 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2GM20
Performance Ratios
Hull Speed:
6.73 knots
SA/Displacement (Calculated):
19.17
SA/Displacement (Reported):
19.57
Ballast/Disp Ratio:
38.78%
Displacement/Length:
189.51
Comfort Ratio:
17.06
Capsize Screening:
2.24
S-Number:
3.13
Notes
Based on IOR 1/2 ton design.
