SUN FIZZ 40 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Philippe Briand
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1980
Last Built:
1984
Dimensions
Length Overall (LOA):
12.30 m
Length Waterline (LWL):
10.21 m
Beam:
3.85 m
Draft (Max):
1.95 m
Weight & Ballast
Displacement:
7,303 kg
Ballast:
2,998 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
32.28 m²
Mainsail Area:
29.89 m²
Total Sail Area (calculated):
62.17 m²
Sail Area (reported):
62.15 m²
I (Fore Triangle Height):
15.24 m
J (Fore Triangle Base):
4.24 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
4.36 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Power:
50 HP
Performance Ratios
Hull Speed:
7.76 knots
SA/Displacement (Calculated):
16.52
SA/Displacement (Reported):
16.85
Ballast/Disp Ratio:
41.06%
Displacement/Length:
191.18
Comfort Ratio:
23.89
Capsize Screening:
2.00
S-Number:
2.80
Notes
A similar model was sold in the US as the O'DAY 39, (O'DAY 40 after redesign.)
