STUART 37
Built by Stuart Yachtbuilding Ltd. (UK)
• Designed by Alex Stuart
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1978
Dimensions
Length Overall (LOA):
11.28 m
Length Waterline (LWL):
9.60 m
Beam:
3.51 m
Draft (Min):
1.98 m
Weight & Ballast
Displacement:
6,350 kg
Ballast:
3,316 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
37.16 m²
Mainsail Area:
23.57 m²
Total Sail Area (calculated):
60.73 m²
Sail Area (reported):
60.76 m²
I (Fore Triangle Height):
15.24 m
J (Fore Triangle Base):
4.88 m
P (Mainsail Hoist):
13.27 m
E (Boom Length):
3.55 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD 11C
Engine Power:
28 HP
Fuel Capacity:
57 L
Water Capacity:
189 L
Performance Ratios
Hull Speed:
7.52 knots
SA/Displacement (Calculated):
17.71
SA/Displacement (Reported):
18.08
Ballast/Disp Ratio:
52.22%
Displacement/Length:
199.96
Comfort Ratio:
25.23
Capsize Screening:
1.91
S-Number:
2.83
Notes
from original brochure.
