STJÄRNBÅT
Built by Bothén, Bertil
• Designed by Janne Jacobsson
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
Wood-clinker
First Built:
1913
Last Built:
1930
Number Built:
500
Dimensions
Length Overall (LOA):
5.50 m
Beam:
1.60 m
Draft (Max):
0.73 m
Weight & Ballast
Displacement:
500 kg
Ballast:
200 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
14.96 m²
Engine & Systems
Performance Ratios
SA/Displacement (Reported):
24.19
Ballast/Disp Ratio:
40.02%
Capsize Screening:
2.04
Notes
Original boats built in Sweden. STJÄRNBÅT = 'Star Boat ??". A very popular one-design class in to the 1960s. A similar version, but with a slightly smaller rig, was called the VINGBÅT and built in Finland beginning in 1930. Of these, over 100 were built.
