STARWIND 27
Built by Starwind/Wellcraft/Chrysler (USA)
• Designed by Jim Taylor
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Dimensions
Length Overall (LOA):
8.13 m
Length Waterline (LWL):
6.86 m
Beam:
2.95 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
2,359 kg
Ballast:
907 kg
Sail Plan
Foresail Area:
16.83 m²
Mainsail Area:
15.29 m²
Total Sail Area (calculated):
32.12 m²
Sail Area (reported):
32.14 m²
I (Fore Triangle Height):
10.52 m
J (Fore Triangle Base):
3.20 m
P (Mainsail Hoist):
8.99 m
E (Boom Length):
3.40 m
Engine & Systems
Water Capacity:
53 L
Performance Ratios
Hull Speed:
6.36 knots
SA/Displacement (Calculated):
18.13
SA/Displacement (Reported):
18.50
Ballast/Disp Ratio:
38.46%
Displacement/Length:
203.80
Comfort Ratio:
16.47
Capsize Screening:
2.24
S-Number:
2.83
Notes
Shoal draft version: 3.58'/1.09m
