ST FRANCIS 460
Built by St. Francis Marine (RSA)
• Designed by Anton du Toit and Angelo Lavranos
General Information
Hull Type:
Catamaran Twin Keel
Rigging Type:
Fractional Sloop
Construction:
Composite / Vinyl Ester resin infused core cell foam sandwich, carbon fiber reinforced
First Built:
2024
Dimensions
Length Overall (LOA):
13.98 m
Length Waterline (LWL):
13.87 m
Beam:
8.00 m
Draft (Max):
1.24 m
Max Height:
21.10 m
Weight & Ballast
Displacement:
13,500 kg
Sail Plan
Foresail Area:
38.54 m²
Mainsail Area:
57.38 m²
Total Sail Area (calculated):
95.92 m²
Sail Area (reported):
116.20 m²
I (Fore Triangle Height):
16.40 m
J (Fore Triangle Base):
4.70 m
P (Mainsail Hoist):
17.00 m
E (Boom Length):
6.75 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Hybrid electric/diesel
Engine Power:
2x 40 HP
Fuel Capacity:
700 L
Water Capacity:
800 L
Performance Ratios
SA/Displacement (Calculated):
16.92
SA/Displacement (Reported):
20.92
Displacement/Length:
140.96
S-Number:
3.55
