SPIRIT 46 (McMILLAN)
Built by Spirit Yachts (UK)
• Designed by Sean McMillan
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
Wood
First Built:
2002
Dimensions
Length Overall (LOA):
14.15 m
Length Waterline (LWL):
10.30 m
Beam:
2.83 m
Draft (Max):
2.00 m
Max Height:
18.60 m
Weight & Ballast
Displacement:
4,500 kg
Ballast:
2,024 kg
Ballast Type:
Lead bulb
Sail Plan
Sail Area (reported):
63.55 m²
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
GM-20
Engine Power:
18 HP
Fuel Capacity:
49 L
Water Capacity:
95 L
Performance Ratios
Hull Speed:
7.79 knots
SA/Displacement (Reported):
23.78
Ballast/Disp Ratio:
44.98%
Displacement/Length:
114.80
Comfort Ratio:
20.98
Capsize Screening:
1.73
