SPINDRIFT 22
Built by Rebel Industries
• Designed by Jim Taylor
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1982
Last Built:
1987
Number Built:
400
Dimensions
Length Overall (LOA):
6.55 m
Length Waterline (LWL):
5.82 m
Beam:
2.49 m
Draft (Max):
1.42 m
Draft (Min):
0.46 m
Weight & Ballast
Displacement:
903 kg
Ballast:
272 kg
Sail Plan
Foresail Area:
8.92 m²
Mainsail Area:
9.15 m²
Total Sail Area (calculated):
18.07 m²
Sail Area (reported):
18.02 m²
I (Fore Triangle Height):
7.80 m
J (Fore Triangle Base):
2.29 m
P (Mainsail Hoist):
6.52 m
E (Boom Length):
2.80 m
Engine & Systems
Performance Ratios
Hull Speed:
5.85 knots
SA/Displacement (Calculated):
19.33
SA/Displacement (Reported):
19.66
Ballast/Disp Ratio:
30.15%
Displacement/Length:
127.90
Comfort Ratio:
9.48
Capsize Screening:
2.60
S-Number:
4.13
Notes
Originally built by Spectrum Yachts in FL, USA and called the SPECTRUM 22.
