SOVEREIGN 24
Built by Custom Fiberglass Products (USA)
• Designed by Arthur Edmunds/Sovereign
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1981
Last Built:
1996
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
5.64 m
Beam:
2.44 m
Draft (Max):
0.79 m
Weight & Ballast
Displacement:
1,633 kg
Ballast:
544 kg
Sail Plan
Foresail Area:
13.34 m²
Mainsail Area:
9.08 m²
Total Sail Area (calculated):
22.42 m²
Sail Area (reported):
22.39 m²
I (Fore Triangle Height):
8.84 m
J (Fore Triangle Base):
3.02 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
2.59 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calculated):
16.17
SA/Displacement (Reported):
16.46
Ballast/Disp Ratio:
33.33%
Displacement/Length:
253.83
Comfort Ratio:
17.30
Capsize Screening:
2.09
S-Number:
2.09
Notes
A version with a deeper keel (3.67') was also available.
