SOTO 40
Built by M Boats (ARG)
• Designed by Javier Soto Acebal
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
E-Glass/Epoxy/PVC foam
First Built:
2008
Number Built:
35
Dimensions
Length Overall (LOA):
12.30 m
Length Waterline (LWL):
12.30 m
Beam:
3.75 m
Draft (Max):
2.60 m
Weight & Ballast
Displacement:
4,290 kg
Ballast:
2,180 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
38.92 m²
Mainsail Area:
47.27 m²
Total Sail Area (calculated):
86.19 m²
Sail Area (reported):
86.21 m²
I (Fore Triangle Height):
16.05 m
J (Fore Triangle Base):
4.85 m
P (Mainsail Hoist):
16.30 m
E (Boom Length):
5.80 m
Engine & Systems
Engine Make:
Volvo Penta (saildrive)
Engine Type:
Diesel
Engine Model:
D1-30
Engine Power:
30 HP
Fuel Capacity:
49 L
Performance Ratios
Hull Speed:
8.51 knots
SA/Displacement (Calculated):
32.65
SA/Displacement (Reported):
33.31
Ballast/Disp Ratio:
50.81%
Displacement/Length:
64.27
Comfort Ratio:
12.81
Capsize Screening:
2.33
S-Number:
7.72
Notes
Raced as a one design class for a number of years.
