SNAPDRAGON 747
Built by Thames Marine (UK)
• Designed by Thames Structural Plastics/Thames Marine
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Twin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1964
Dimensions
Length Overall (LOA):
7.47 m
Length Waterline (LWL):
6.25 m
Beam:
2.44 m
Draft (Max):
0.76 m
Weight & Ballast
Displacement:
1,678 kg
Ballast:
703 kg
Sail Plan
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
YS 8
Performance Ratios
Hull Speed:
6.07 knots
Ballast/Disp Ratio:
41.89%
Displacement/Length:
191.73
Comfort Ratio:
16.51
Capsize Screening:
2.07
Notes
An upgraded version of the SNAPDRAGON 24. Slightly modified rig, and redesigned rudder and skeg. Bilge or standard keel models were produced.
