SINGOALLA 34 (ALBIN)
Built by Albin Marine (SWE)
• Designed by Per Brohäll
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Dimensions
Length Overall (LOA):
10.26 m
Length Waterline (LWL):
8.33 m
Beam:
3.30 m
Draft (Max):
1.58 m
Weight & Ballast
Displacement:
4,001 kg
Ballast:
1,701 kg
Sail Plan
Foresail Area:
26.21 m²
Mainsail Area:
20.46 m²
Total Sail Area (calculated):
46.67 m²
Sail Area (reported):
46.54 m²
I (Fore Triangle Height):
12.60 m
J (Fore Triangle Base):
4.16 m
P (Mainsail Hoist):
10.49 m
E (Boom Length):
3.90 m
Engine & Systems
Engine Make:
Albin
Engine Type:
Diesel
Engine Model:
AD-21
Engine Power:
22 HP
Performance Ratios
Hull Speed:
7.01 knots
SA/Displacement (Calculated):
18.52
SA/Displacement (Reported):
18.84
Ballast/Disp Ratio:
42.52%
Displacement/Length:
192.89
Comfort Ratio:
19.55
Capsize Screening:
2.10
S-Number:
3.01
Notes
Designed as a larger version of the successful VEGA 27. It sold poorly and remained in production for only a short time.
