SIGNET 20
Built by Signet Marine, Ltd. Hurley Marine Ltd.
• Designed by Ray Kaufmann
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1960
Dimensions
Length Overall (LOA):
6.04 m
Length Waterline (LWL):
4.88 m
Beam:
2.03 m
Draft (Max):
0.91 m
Weight & Ballast
Displacement:
973 kg
Ballast:
363 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
7.28 m²
Mainsail Area:
8.38 m²
Total Sail Area (calculated):
15.66 m²
Sail Area (reported):
15.70 m²
I (Fore Triangle Height):
7.16 m
J (Fore Triangle Base):
2.03 m
P (Mainsail Hoist):
6.25 m
E (Boom Length):
2.68 m
Engine & Systems
Performance Ratios
Hull Speed:
5.36 knots
SA/Displacement (Calculated):
15.95
SA/Displacement (Reported):
16.29
Ballast/Disp Ratio:
37.28%
Displacement/Length:
233.90
Comfort Ratio:
15.43
Capsize Screening:
2.07
S-Number:
2.26
Notes
THE SIGNET 20 was built both in the USA and the UK. A number of versions were produced: fixed or bilge keels, skeg or transom mounted rudders, etc/ Later UK models built by Gilmax Ltd became a Mark 2 version, known as a Signet Super 20. Inboard power was available as an option.
