SHOW 27
Built by Cantieri Barberis (ITA)
• Designed by Delio Barberis/Lanfranco Soma
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1978
Dimensions
Length Overall (LOA):
8.38 m
Length Waterline (LWL):
6.71 m
Beam:
2.95 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
1,814 kg
Ballast:
650 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
14.89 m²
Mainsail Area:
11.80 m²
Total Sail Area (calculated):
26.69 m²
Sail Area (reported):
27.69 m²
I (Fore Triangle Height):
9.46 m
J (Fore Triangle Base):
3.15 m
P (Mainsail Hoist):
8.28 m
E (Boom Length):
2.85 m
Engine & Systems
Performance Ratios
Hull Speed:
6.29 knots
SA/Displacement (Calculated):
17.94
SA/Displacement (Reported):
18.97
Ballast/Disp Ratio:
35.83%
Displacement/Length:
167.70
Comfort Ratio:
12.73
Capsize Screening:
2.44
S-Number:
3.29
Notes
Thanks to SHOW 27 owner "Rob" for the photo.
