SHAW 24 YAWL
Built by A. Jenson and Son (DEN)
• Designed by William Shaw
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Yawl
Construction:
Wood/FG
First Built:
1957
Dimensions
Length Overall (LOA):
7.29 m
Length Waterline (LWL):
5.64 m
Beam:
2.26 m
Draft (Max):
1.60 m
Draft (Min):
0.84 m
Weight & Ballast
Displacement:
2,177 kg
Ballast:
680 kg
Ballast Type:
lead
Sail Plan
Sail Area (reported):
25.08 m²
Engine & Systems
Engine Make:
Kermath
Engine Type:
Gas
Engine Model:
Sea Twin
Engine Power:
10 HP
Fuel Capacity:
38 L
Water Capacity:
76 L
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Reported):
15.23
Ballast/Disp Ratio:
31.25%
Displacement/Length:
338.44
Comfort Ratio:
25.52
Capsize Screening:
1.76
Notes
This boat was drawn by William Shaw while he was working in the S&S office. It is the predecessor to the DOLPHIN 24. First boats were built of wood in Denmark. The first boat, 'Trina', was extremely successful as a racer. A few later hulls were turned out in fiberglass by Bob Marsh, John Wells and Chip Morse operating out of La Porte, TX. Some boats were delivered as sloops.
