SHARK 24
Built by Hinterhoeller Yachts Ltd.
• Designed by George Hinterhoeller
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1959
Number Built:
2500
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
6.10 m
Beam:
2.08 m
Draft (Max):
0.96 m
Weight & Ballast
Displacement:
998 kg
Ballast:
306 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
6.78 m²
Mainsail Area:
10.90 m²
Total Sail Area (calculated):
17.68 m²
Sail Area (reported):
17.65 m²
I (Fore Triangle Height):
6.10 m
J (Fore Triangle Base):
2.23 m
P (Mainsail Hoist):
7.01 m
E (Boom Length):
3.11 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
17.70
SA/Displacement (Reported):
18.01
Ballast/Disp Ratio:
30.68%
Displacement/Length:
122.77
Comfort Ratio:
12.40
Capsize Screening:
2.10
S-Number:
3.96
Notes
The first SHARK was built of plywood. But when designer/builder George Hinterhoeller started building them of fiberglass he couldn't keep up with demand and the design became an international success.
