SHANNON 43
Built by Shannon Yachts (USA)
• Designed by Walter Shultz
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Staysail Ketch
Construction:
FG
First Built:
1986
Dimensions
Length Overall (LOA):
13.36 m
Length Waterline (LWL):
11.15 m
Beam:
3.96 m
Draft (Max):
2.62 m
Draft (Min):
1.45 m
Weight & Ballast
Displacement:
12,247 kg
Ballast:
4,536 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
49.63 m²
Mainsail Area:
35.85 m²
Total Sail Area (calculated):
85.48 m²
Sail Area (reported):
84.54 m²
I (Fore Triangle Height):
16.92 m
J (Fore Triangle Base):
5.87 m
P (Mainsail Hoist):
14.86 m
E (Boom Length):
4.82 m
Engine & Systems
Engine Make:
Mercedes
Engine Type:
Diesel
Engine Power:
60 HP
Fuel Capacity:
379 L
Water Capacity:
757 L
Performance Ratios
Hull Speed:
8.10 knots
SA/Displacement (Calculated):
16.09
SA/Displacement (Reported):
16.24
Ballast/Disp Ratio:
37.04%
Displacement/Length:
246.25
Comfort Ratio:
35.37
Capsize Screening:
1.74
S-Number:
2.15
Notes
Fixed keel version draft: 6.5'.
