SHANNON 38
Built by Shannon Yachts (USA)
• Designed by G, H. Stadel & Son/Schultz & Assoc.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1975
Last Built:
1988
Number Built:
100
Dimensions
Length Overall (LOA):
11.51 m
Length Waterline (LWL):
9.40 m
Beam:
3.51 m
Draft (Max):
1.52 m
Headroom:
1.96 m
Weight & Ballast
Displacement:
8,391 kg
Ballast:
2,948 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.58 m²
Mainsail Area:
25.36 m²
Total Sail Area (calculated):
61.94 m²
Sail Area (reported):
65.31 m²
I (Fore Triangle Height):
13.72 m
J (Fore Triangle Base):
5.33 m
P (Mainsail Hoist):
11.89 m
E (Boom Length):
4.27 m
Engine & Systems
Engine Make:
Westerbeke
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
265 L
Water Capacity:
454 L
Performance Ratios
Hull Speed:
7.44 knots
SA/Displacement (Calculated):
15.00
SA/Displacement (Reported):
16.14
Ballast/Disp Ratio:
35.14%
Displacement/Length:
281.84
Comfort Ratio:
33.59
Capsize Screening:
1.74
S-Number:
1.75
Notes
The SHANNON 38 was the first model by this builder. A few pilot house versions were produced.
