SEAWIND (ALLIED)
Built by Allied Boat Co. (USA)
• Designed by Thomas Gillmer
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Ketch
Construction:
FG
First Built:
1962
Last Built:
1982
Number Built:
161
Dimensions
Length Overall (LOA):
9.30 m
Length Waterline (LWL):
7.32 m
Beam:
2.82 m
Draft (Max):
1.28 m
Weight & Ballast
Displacement:
5,443 kg
Ballast:
1,905 kg
Sail Plan
Foresail Area:
20.25 m²
Mainsail Area:
19.22 m²
Total Sail Area (calculated):
39.47 m²
Sail Area (reported):
46.64 m²
I (Fore Triangle Height):
10.84 m
J (Fore Triangle Base):
3.73 m
P (Mainsail Hoist):
9.70 m
E (Boom Length):
3.96 m
Engine & Systems
Engine Make:
Palmer /Gray Marine
Engine Type:
Gas
Engine Model:
M-60
Fuel Capacity:
45 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.56 knots
SA/Displacement (Calculated):
12.76
SA/Displacement (Reported):
15.38
Ballast/Disp Ratio:
35.00%
Displacement/Length:
387.52
Comfort Ratio:
36.91
Capsize Screening:
1.62
S-Number:
0.96
Notes
Originally designed for Kaiser Gale Force Yachts which sold the molds to Allied Boat Co. After changing the cabin top and port arrangement, the first boat appeared in 1962.
